Biamplified system: |
-MAIN QUALITIES: - High power output - Processed bi-amplification - Active equalization of bass, mid, and treble sounds - Balanced inputs for line and microphone - High reliability - Fly PA ready - Silent internal cooling - 3-year warranty*** .
|
Its main characteristic is the capacity to operate linearly |
AN UNCOMPARABLE COST/BENEFIT RATIO! |
|||||||
. |
.
|
||||||
. |
-TECHNICAL CHARACTERISTICS: |
The CREST-FACTOR processor offers the system an extraordinary and dynamic performance, protecting and ensuring its operations on long lasting applications. Its amplifier is fitted with an AUTO-MUTE, which allows for an always silent activation, even in case of transients and power outage. It is protected against high temperature, short-circuit, network fluctuations, transients, input overload, DC, reactive or mismatched loads, ultrasound and radiofrequency, with Soft-Clip, and Soft-Start activation. |
Frequency response (+/- 3dB) | 35 - 18.000Hz |
SPL max. (1m) | 129 dB |
Coverage angle | 60x40 degrees |
SPL of residual noise (A Curve) | 31dB |
Input signal level for maximum output | 0,5V RMS adjustable on the rear panel |
Input impedance (balanced) XLR | 10K Ohm (P2 = +, P3 = -, P1=commom) |
Crossover | 1500Hz, 24 dB/8a active |
3-Band equalizer | +/- 10dB at 100Hz, 1KHz and 10KHz |
Power amplifiers: - Loudspeakers - Driver |
700 W RMS 4 Ohm 70 W RMS |
Power | 120V AC and 220V AC (or any custom voltages) |
Operating room temperature | 0 a +45 degrees |
Dimensions (width X height X depth) | 470mm X 13500mm X 470mm (trapezoidal) |
Weight | 54kg |
Cabinets with side grips to make transportation easier, made in high-quality multi-layered plywood with pressure injected structural resin, high-strength painting, reinforced corners in ABS, and front protection steel grid treated against corrosion.. |
|
A 3-year warranty for electronic circuits and assembly.*** .(***) Valid for products sold in Brazil. Check with your dealer for local warranty). |
